Home☸Modal Exciters Overview

Reset Select







Modal



Exciter



Model

  • Max Force(Forced Cooled)
  • Max Force(Natural Cooled)
  • Frequency Range[Hz]
  • Resonance Frequency[Hz]
  • Max Displacement[mm p-p]
  • Equivalent Mass[kg]
  • Max Acceleration[g]
  • Weight[kg]
  • Thread[ø mm]
  • Size[mm*mm*mm]
  • Max Current[A]
  • product image

    PME50

    • -
    • 50N
    • DC-10000
    • 10000+
    • 18
    • 0.13
    • 40
    • 2
    • M6
    • 184*95*188
    • 4
  • product image

    PME100

    • -
    • 100N
    • DC-10000
    • 10000+
    • 18
    • 0.13
    • 80
    • 2
    • M6
    • 184*95*188
    • 8
  • product image

    PME100+

    • -
    • 100N
    • DC-8000
    • 5700
    • 20
    • 0.35
    • 35
    • 14.5
    • M6
    • 200*265*250
    • 5
  • product image

    PME200

    • 200N
    • 100N
    • DC-8000
    • 5800
    • 20
    • 0.32
    • 70
    • 14.5
    • M6
    • 200*265*250
    • 10
  • product image

    PME250

    • 250N
    • 130N
    • DC-8000
    • 5800
    • 20
    • 0.32
    • 85
    • 14.5
    • M6
    • 200*265*250
    • 10
  • product image

    PME300

    • 300N
    • 150N
    • DC-8000
    • 5800
    • 20
    • 0.32
    • 100
    • 15
    • M6
    • 200*265*250
    • 10
  • product image

    PME500

    • 500N/350N
    • 220N/175N
    • DC-6000
    • 4700
    • 20
    • 0.45
    • 100
    • 16
    • M6
    • 200*265*250
    • 10
  • product image

    PME1000

    • 1000N/700N
    • 500N/350N
    • DC-4500
    • 3900
    • 25
    • 1
    • 100
    • 41
    • M6
    • 351*267*340
    • 13

*All systems are equipted with over-displacement, over-voltage, over-current and over-temperature interlocks(or integrated functions).

*For more detailed info, please contact Metron technical department.
