Home☸Permanent Magnetic Shaker Tables Overview

Reset Select







Shaker



Table



Model

  • Max Force(Forced Cooled)
  • Max Force(Natural Cooled)
  • Frequency Range[Hz]
  • Resonance Frequency[Hz]
  • Max Displacement[mm p-p]
  • Equivalent Mass[kg]
  • Max Acceleration[g]
  • Weight[kg]
  • Table+Thread[ø mm]
  • Size[mm*mm*mm]
  • Max Current[A]
  • product image

    PMG50

    • -
    • 50N
    • 5-10000
    • 8825
    • 10
    • 0.25
    • 20
    • 2
    • ø30 + 4*M5
    • 184*95*188
    • 4
  • product image

    PMG100

    • -
    • 100N
    • 5-10000
    • 8825
    • 10
    • 0.25
    • 35
    • 2
    • ø30 + 4*M5
    • 184*95*188
    • 8
  • product image

    PMG100+

    • -
    • 100N
    • 5-7500
    • 4800
    • 12
    • 0.4
    • 35
    • 14.5
    • ø50 + 4*M5
    • 200*265*250
    • 5
  • product image

    PMG200

    • 200N
    • 100N
    • 5-6500
    • 4800
    • 12
    • 0.4
    • 50
    • 14.5
    • ø50 + 4*M5
    • 200*265*250
    • 10
  • product image

    PMG300

    • 300N
    • 150N
    • 5-6500
    • 4800
    • 12
    • 0.45
    • 65
    • 15
    • ø50 + 4*M5
    • 200*265*250
    • 10
  • product image

    PMG500

    • 500N/350N
    • 220N/175N
    • 5-5000
    • 3560
    • 15
    • 0.63
    • 85
    • 16
    • ø50 + 4*M5
    • 200*265*250
    • 10
  • product image

    PMG1000

    • 1000N/700N
    • 500N/350N
    • 5-4500
    • 3100
    • 15
    • 1.2
    • 90
    • 41
    • ø60 + 4*M6
    • 351*267*340
    • 13

*All systems are equipted with over-displacement, over-voltage, over-current and over-temperature interlocks(or integrated functions).

*For more detailed info, please contact Metron technical department.
